2026 Yamaha Yzf-R1M Carbon Fiber

2026 Yamaha YZF-R1M Carbon Fiber

THE ULTIMATE R

Yamaha's highest specification Supersport, the 2026 YZF-R1M comes adorned in striking carbon fiber bodywork including MotoGP®-inspired winglets, distinctive R1M styling and an engraved serial number badge to further highlight its exclusivity. Taking all the explosive performance and capability of the YZF-R1 to an even higher level, the R1M's advanced Öhlins® Electronic Racing Suspension works with a dedicated Suspension Control Unit to rapidly adjust front and rear damping in real time, whether braking, cornering or accelerating.

Features may include:

MotoGP®-Inspired Winglets

• Developed through extensive simulator and on-track testing, MotoGP®-inspired carbon fiber winglets create additional downforce for exceptional chassis stability and added front-end feel when braking or cornering.

MotoGP®-Derived Crossplane Crankshaft Engine

• The YZF-R1M's 998cc inline-four-cylinder engine features Yamaha's exclusive crossplane crankshaft technology derived from the YZR-M1 MotoGP® race bike. By equalizing inertial forces at the crankshaft, the CP4 motor delivers a direct feeling of linear torque, giving the rider the ultimate connection between throttle grip and the rear wheel.

Dynamic Öhlins® Electronic Racing Suspension

• The YZF-R1M utilizes the advanced Öhlins® ERS system, featuring the NPX gas-charged front fork. A dedicated suspension control unit rapidly adjusts the front and rear damping in real time for optimum suspension performance whether braking, cornering or accelerating.

Digital Superbike Technology

• The YZF-R1M features a cableless ride-by-wire Yamaha Chip Controlled Throttle (YCC-T) system that transforms the rider's inputs into motion, with a full suite of IMU-powered electronic rider aids that bring new meaning to the term "rider confidence." The R1M also features a Communication Control Unit (CCU) as standard enabling a GPS-tracked lap timer, data recorder from the IMU, ECU and GPS, and mobile phone/tablet YRC adjustability.

Sharp Styling with Unique R1M Features

• The YZF-R1 features beautifully integrated bodywork and sleek, stylish lines which create an unmistakably aggressive, aerodynamic profile. R1M riders are treated to even higher levels of fit and finish thanks to full carbon-fiber bodywork, including a carbon windscreen fairing, side fairings, front fender and tail section, matched to a polished aluminum swingarm and topped with a unique serial-numbered YZF-R1M badge on top of the airbox cover.

ENGINE

• Advanced 998cc CP4 engine with crossplane crankshaft technology.
• Lightweight titanium connecting rods, titanium intake valves and forged pistons.
• Variable Yamaha Chip Controlled Intake (YCC-I) system adjusts length of intake based on engine speed.
• Compact rocker-arm valve actuation allow for greater valve lift.
• Lightweight titanium muffler and heat shield reduce weight, centralize mass.
• Compact, stacked 6-speed transmission features close-ratio gearing.
• Advanced Assist & Slipper clutch provides confident downshifts.

ELECTRONICS

• Ride-by-wire Yamaha Chip Controlled Throttle (YCC-T) system enables cutting-edge computerized engine management.
• Yamaha's lean-sensitive Brake Control (BC) System works with ABS to provide progressive brake force intervention as lean increases.
• Three-level Engine Brake Management (EBM) system allows rider to adjust engine braking to suit preference.
• Four-level Power Delivery Mode (PWR) allows rider to adjust engine response to suit preference.
• Lean angle-sensitive Traction Control (TCS) incorporates 6-axis IMU to adjust intervention to suit rider preference.
• Four-level Slide Control System (SCS) detects lateral slides and adjusts power delivery to control cornering attitude.
• Four-level Lift Control System (LIF) detects front wheel lift and regulates engine power to maintain chassis attitude and forward drive.
• Three-level Launch Control System (LCS) limits engine RPM and throttle opening to maximize acceleration from a standing start.
• An integrated GPS data-logging system is enabled through Yamaha's Communication Control Unit offering vehicle data recording with course mapping and automatic lap timing.
• Quick Shift System (QSS) with three settings enables clutchless upshifting and downshifting.

CHASSIS/SUSPENSION

• Slim, compact aluminum Deltabox frame for optimal rigidity and outstanding track-focused handling.
• Dynamic Öhlins® Electronic Racing Suspension (ERS) works with the IMU to adjust suspension in real time for optimum performance.
• Öhlins® gas-charged NPX fork delivers consistent damping with exceptional ride quality and feel.
• Radial-mounted 4-piston front brake calipers, high-friction pad compound and braided stainless steel lines provide firm response and precise feel.
• Premium 10-spoke cast magnesium wheels significantly lower unsprung weight and rotational mass.
• High performance Bridgestone® RS11 tires offer track-worthy handling, superb traction and balanced feel.

ADDITIONAL FEATURES

• Advanced, full-color TFT display offers selectable layouts and a wide range of vehicle information.
• Full LED lighting offers a broad spread of illumination and high visibility.
• Unique R1M styling features include full carbon-fiber bodywork, polished aluminum swingarm and Special Edition color scheme.
• Seat cover texture balances both grip and ease of movement for a better sense of connection and control.
